Maintenance, Troubleshooting, and Technical Specifications
53
Idle current (Hands-free) 136 mA
Scanning current (Hand-held) 356 mA
Scanning current (Hands-free) 330 mA
Performance Characteristics
Aiming Dot
DS9908-SR/DL
DS9908-HD/HL
Amber 617nm LED
True Green 528nm LED
Illumination
DS9908-SR/DL
DS9908-HD/HL
Deep Red 657nm LED
Warm White 2700K LED
Field of View
(Horizontal x Vertical) Nominal
48° H x 30.6° V
Image Sensor 1280 x 800 pixels
Minimum Print Contrast 16% minimum reflective difference
Skew Tolerance +/- 60°
Pitch Tolerance +/- 60°
Roll Tolerance 0-360°
Image Capture
Graphics Format Support Images can be exported as Bitmap, JPEG, or TIFF
Resolution (A4 document) 109 PPI
User Environment
Operating Temperature 32º F to 122º F (0º C to 50º C)
Storage Temperature -40° to 158°F / -40° to 70°C
Humidity 5% to 95% RH, non-condensing
Drop Specifications Designed to withstand multiple drops at 5.0 ft/1.5 m to concrete
Tumble Specification (Scanner) Designed to withstand 2,000 tumbles in 1.5 ft./0.5 m tumbler
Ambient Light Immunity 0 to 9000 Foot Candles/0 to 96,840 Lux
Environmental Sealing IP52
Electrostatic Discharge (ESD) ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV
Indirect
Table 6 Technical Specifications (Continued)
Item Description
