Zebra DS9908 Product Reference Guide

Imager Preferences
118
Signature Capture Width
Parameter # 366
SSI # F4h F0h 6Eh
The aspect ratio of the Signature Capture Width and Signature Capture Height parameters must match that of the
signature capture area. For example, a 4 x 1 inch signature capture area requires a 4 to 1 aspect ratio of width to
height.
To set the width of the signature capture box, scan the Signature Capture Width barcode, and then scan four
barcodes from Numeric Barcodes corresponding to a value in the range of 16 to 1280 decimal.
Signature Capture Height
Parameter # 367
SSI # F4h F0h 6Fh
To set the height of the signature capture box, scan the Signature Capture Height barcode, and then scan three
barcodes from Numeric Barcodes corresponding to a value in the range of 16 to 960 decimal.
Signature Capture JPEG Quality
Parameter # 421
SSI # F0h A5h
Scan the JPEG Quality Value barcode, and then scan three barcodes from Numeric Barcodes corresponding to a
value from 005 to 100, where 100 represents the highest quality image.
Signature Capture Width (Default: 400)
(16 - 1280 Decimal)
Signature Capture Height (Default: 100)
(16 - 960 Decimal)
JPEG Quality Value (Default: 065)
(5 - 100 Decimal)
