Zebra DS9908

Data Capture
44
Decode Ranges
DS9908-SR/DL/HD/HL Configurations
Table 4 Typical Ranges
Configuration
Code Type
Symbol
Density
Range
SR/DL
(cm/in)
HD/HL
(cm/in)
Code 39 3 mil near 2.9 cm / 1.1 in 3.4 cm / 1.3 in
far 7.7 cm / 3.0 in 9.5 cm / 3.7 in
20 mil near 2.5 cm / 1.0 in 0.8 cm / 0.3 in
far 109.1 cm / 42.9 in 67.6 cm / 26.6 in
Code 128 3 mil near 3.5 cm / 1.4 in 3.7 cm / 1.4 in
far 9.0 cm / 3.5 in 10.6 cm / 4.2 in
5 mil near 2.6 cm / 1.0 in 1.9 cm / 0.8 in
far 18.1 cm / 7.1 in 19.0 cm / 7.5 in
15 mil near 2.6 cm / 1.0 in 2.6 cm / 1.0 in
far 70.3 cm / 27.7 in 50.8 cm / 20.0 in
100% UPC 13 mil near 0.0 cm / 0.0 in 0.0 cm / 0.0 in
far 62.6 cm / 24.7 in 48.5 cm / 19.1 in
PDF417 5 mil near 3.6 cm / 1.4 in 3.2 cm / 1.2 in
far 12.7 cm / 5.0 in 14.5 cm / 5.7 in
6.67 mil near 3.1 cm / 1.2 in 2.1 cm / 0.8 in
far 20.2 cm / 8.0 in 20.2 cm / 8.0 in
Data Matrix 5.0 mil near
N/A
6.8 cm / 2.7 in
far
N/A
9.1 cm / 3.6 in
7.5 mil near 3.0 cm / 1.2 in 3.2 cm/ 1.3 in
far 17.4 cm / 6.9 in 16.6 cm / 6.5 in
10 mil near 3.3 cm / 1.3 in 1.2 cm / 0.5 in
far 23.6 cm / 9.3 in 23.7 cm / 9.3 in
QR Code 10 mil near 2.5 cm / 1.0 in 1.3 cm / 0.5 in
far 19.3 cm / 7.6 in 18.4 cm / 7.2 in
20 mil near 2.6 cm / 1.0 in 0.0 cm / 0.0 in
far 45.7 cm / 18.0 in 34.8 cm / 13.7 in
