Zebra DS9908 Product Reference Guide

Imager Preferences
97
Crop to Pixel Addresses 315
316
317
318
F4h F0h 3Bh
F4h F0h 3Ch
F4h F0h 3Dh
F4h F0h 3Eh
0 top
0 left
799 bottom
1279 right
105
Image Size (Number of Pixels) 302 F0h 2Eh Full 107
Image Brightness (Target White) 390 F0h 86h 180 109
JPEG Image Options 299 F0h 2Bh Quality 109
JPEG Quality Value 305 F0h 31h 65 110
JPEG Size Value 561 F1h 31h 160 kB 110
Image Enhancement 564 F1h 34h Low (1) 111
Image File Format Selection 304 F0h 30h JPEG 112
Image Rotation 665 F1h 99h 0 113
Bits per Pixel (BPP) 303 F0h 2Fh 8 BPP 114
Signature Capture 93 5Dh Disable 115
Signature Capture Image File Format
Selection
313 F0h 39h JPEG 116
Signature Capture Bits per Pixel (BPP) 314 F0h 3Ah 8 BPP 117
Signature Capture Width 366 F4h F0h 6Eh 400 118
Signature Capture Height 367 F4h F0h 6Fh 100 118
Signature Capture JPEG Quality 421 F0h A5h 65 118
Video Mode Format Selector 916 F2h 94h JPEG 119
Video View Finder 324 F0h 44h Disable 119
Target Video Frame Size 328 F0h 48h 2200 bytes 120
Video View Finder Image Size 329 F0h 49h 1700 bytes 120
Video Subsampling 667 F1h 9Bh 1/4 Resolution 108
Table 9 Image Capture Preferences Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI
Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
