CAPINTEC, INC. CAPTUS
®
4000e
November 16 DICOM 17-7
AE Title
This indicates the AE Title of the DICOM Modality Worklist Provider (e.g.,
"WORKLIST").
Host Name
This indicates the Host Name (e.g., Worklist) or IP address (e.g., "127.0.0.1") of the
DICOM Modality Worklist Provider.
Port
This indicates the TCP/IP port number of the DICOM Modality Worklist Provider.
(e.g., "104")
Service List
The service list is automatically filled in. It should only be changed by support
personnel.
Worklist Threshold
Sets the max number of DICOM Worklist records that can be retrieved before the
Cap-DICOM software issues a Query Cancel request to the DICOM Worklist provider.
The Cap-DICOM software will terminate the association if it receives twice the
threshold number of Worklist records.
Modality
This sets the default modality code for Worklist queries. Modalities are encoded as
per the DICOM standard. NM is Nuclear Medicine, and PT is Positron Emission
Tomography. DICOM only supports one Modality per query.
Query AE Title
This sets the default scheduled station AE title. This can be different than local AE
Title.
Echo Button
This button performs a DICOM Echo using the information configured on this page
and the local DICOM settings page to test the DICOM association to the Worklist
Provider. The results are displayed in the test window next to the echo button.
After entering the data, select the Echo button to confirm that the WORKLIST
SERVER is communicating with the CAPTUS
®
4000e. The message “Successful
Echo, Success” will be displayed as shown in Figure 17-6.
Select the Save button to save the changes or select the Cancel button to cancel the
changes.
Once saved, the Worklist Provider will be displayed in the list as shown in Figure
17-7.
