CAPINTEC, INC. CAPTUS
®
4000e
4-4 GENERAL SETUP November 16
The instrument should be stored where the barometric pressure is within a range of 15–33
inches of mercury (51–112 kilopascals).
CAUTION: If these environmental requirements are not followed, the instrument may
display erroneous readings.
POWER REQUIREMENTS
CAUTION: If the input voltage is not within the stated limits, the unit may not
function correctly or may be damaged.
Input Power
Line Voltage: ............. 115 or 230 Vac depending on model ordered
Line Frequency: ......... 60 or 50 Hz
Current: ..................... 2.6 Ampere @ 115V
1.1 Ampere @ 230V
Fuse: For 115V use T 3.15AH, 250V, (Time Delay)
For 230V use T 2.5AH, 250V, (Time Delay)
Isolation Transformer Output
Computer and Monitor combined
Output Voltage: ......... 115Vac
Current Output: ......... 2.9A
Frequency: ................ 50/60Hz
Printer
Output Voltage: ......... 115Vac
Current Output: ......... 0.7A
Frequency: ................ 50/60Hz
CAP-MCA
Output Voltage: ......... +5Vdc
Current Output: ......... 3.0A
TURN ON PROCEDURE
Verify all system components are mounted securely and all cables are connected. Connect
the Isolation Transformer main power cable to a medical grade wall socket.
All software necessary for proper operation of your CAPTUS
®
4000e Thyroid Uptake System
has been pre-installed and tested at the factory to ensure trouble-free setup.
