CAPINTEC, INC. CAPTUS
®
4000e
10-14 LAB TESTS November 16
Figure 10-20
To measure the patient sample, place the sample in the well and select the OK button.
To quit counting, select the Cancel button and Figure 10-19 will appear.
8. Select the Exit button or press Alt+E after the cycle of measurements is completed to
return to Figure 10-2 Schilling Test Main Screen. The Patient Status box will show the
calculated result for the test. For a detailed report, refer to Patients Reports on page 10-
15.
Data Acquisition
The data acquisition screen appears as shown in Figure 10-21, which displays the
live spectrum as counts are being collected.
Figure 10-21
To stop the counting midway and begin counting again, select the Re-Measure
button or press Alt+R.
