ENGINE CONTROLS 1F–23
DAEWOO M-150 BL2
Multiple ECM Information Sensor DTCs Set (Cont’d)
Step Action Value(s) Yes No
12
Locate and repair the short to voltage in the TP
sensor signal circuit.
Is the repair complete?
–
Go to Step 19
–
13
Locate and repair the short to voltage in the IAT
sensor signal circuit.
Is the repair complete?
–
Go to Step 19
–
14
Locate and repair the short to voltage in the ECT
sensor signal circuit.
Is the repair complete?
–
Go to Step 19
–
15
Locate and repair the short to voltage in the EEGR
Pintle Position sensor circuit.
Is the repair complete?
–
Go to Step 19
–
16
Measure the voltage of the Fuel Tank Pressure
sensor signal circuit between the ECM harness
connector and ground.
Does the voltage measure near the specified value? 0 V Go to Step 18 Go to Step 17
17
Locate and repair the short to voltage in the Fuel
Tank Pressure sensor signal circuit.
Is the repair complete?
–
Go to Step 19
–
18
Replace the ECM.
Is the repair complete?
–
Go to Step 19
–
19
1. Using the scan tool, clear the Diagnostic Trouble
Codes (DTCs).
2. Start the engine and idle at normal operating
temperature.
3. Operate the vehicle within the conditions for
setting the DTCs as specified in the supporting
text.
Does the scan tool indicate that this diagnostic ran
and passed?
–
Go to Step 20 Go to Step 2
20
Check if any additional DTCs are set.
Are any DTCs displayed that have not been
diagnosed?
–
Go to
Applicable DTC
table
System OK
