FIVE-SPEED MANUAL TRANSAXLE 5B–13
DAEWOO M-150 BL2
D12B5731
20. Remove the front exhaust pipe.
D Remove the front exhaust pipe nuts (exhaust
manifold side) (1).
D Remove the gasket and separate exhaust man-
ifold pipe (2).
D Make free the front exhaust pipe.
D13B5111
21. Support the transaxle with the transaxle remove/
install support DW220–030N.
D Position the support on the jack (a).
D Support the transaxle case and mount using a
jack and the transaxle remove/install support.
D103B512
22. Remove the transaxle lower bolt and nut.
a. Lower bolt.
b. Lower nut.
D13B5131
23. Remove the transaxle mount bolts.
