5B–12 FIVE-SPEED MANUAL TRANSAXLE
DAEWOO M-150 BL2
D103B510
12. Remove the transaxle upper bolts.
a. Exhaust manifold side bolt.
b. Thermostat housing side bolt.
D103B505
13. Remove the transaxle under cover.
D Remove the bolts (1).
D Remove the transaxle under cover (2).
14. Remove the front tires and wheels.
D103B506
15. Drain the transaxle fluid.
D Remove the drain plug and drain the fluid.
16. Disconnect the clutch cable.
D Remove the cable adjust nut (1).
D Disconnect the cable from the wire clip (2).
D Disconnect the cable from the transaxle mount
hole (3).
D103B509
17. Remove the front under longitudinal frames and sta-
bilizer. Refer to Section 2C, Front Suspension.
18. Remove the drive axle (only transaxle side). Refer
to Section 3B, Manual Transaxle Drive Axle.
19. Remove the clutch housing lower plate.
D Remove the bolts (1).
D Remove the lower plate (2).
To Next Page
