FIP-1. 2 Restart Printer 001-361/001-363
NoYes
Possible causative parts:PWBA MCU (PL9.1.20)
CHUTE ASSY DUP (PL11.1.1)
Checking the FAN DUP
Does the FAN REAR function
normally?
Checked by [Digital Output] - [DO-5d]
in [IOT Diagnosis].
In the test, close the INTERLOCK
SWITCH.
Replace the PWBA
MCU. (RRP9.7)
Checking the CHUTE
ASSY DUPLEX installation
Reseat the CHUTE ASSY
DUPLEX. (Removal 5/
Replacement 41)
Does the error still
occur when turning
on the power?
NoYes
END
Checking after replacing
the CHUTE ASSY
DUPLEX. (Removal 5/
Replacement 41)
Does the error still
occur when turning
on the power?
NoYes
END
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
