Dell 3115CN - Removal 36 PHOTOCONDUCTOR (PC); DEVELOPER (DEV) DRIVE (PL8.1.2)

3 - 58
Chapter 3 Removal and Replacement Procedures (RRPs)
Version 1 2006.11.28
Removal 36 PHOTOCONDUCTOR (PC) / DEVELOPER (DEV) DRIVE (PL8.1.2)
Steps 1 through 12 are for reference. Before removing this component, check that Steps 1 through 12
have been performed.
1) Open FRONT COVER (PL13.2.1).
2) Remove the FUSER.(Removal 8)
3) Remove the REAR COVER. (Removal 49)
4) Remove the COVER BOTTOM. (Removal 50)
5) Remove the COVER POLE IN R. (Removal 51)
6) Remove the COVER POLE R.(Removal 52)
7) Remove the RIGHT COVER. (Removal 54)
8) Remove the COVER POLE IN L. (Removal 57)
9) Remove the COVER POLE L. (Removal 58)
10) Remove the LEFT COVER. (Removal 59)
11) Remove the TOP COVER. (Removal 68)
When performing the step described below, it is not necessary to disengage the connec-
tor of the INTERLOCK SWITCH.
12) Remove the INTERLOCK SWITCH. (Removal 70)
Continues to the next page.
