1‑308
Chapter 1 Troubleshooting
Version 1 2006.11.21
9. Other FIPs
Shown below are the FIPs for power supply troubles and multiple feed.
FIP-AC
No
Yes
Checking the printer
NoYes
Checking the outlet
Connect the power code
with the other outlet.
Does the printer is
working?
END
NoYes
Checking the power code
connection
Reconnect the power code.
Does the printer is
working?
END
NoYes
Checking the connector of
LVPS connecting
Disconnect the power code
and wait for one minute.
Reseat the all connectors
of LVPS.
Does the printer is
working?
END
Go to DC
Does the motor noise
occur when turning on the
power?In this test, close
the Front Cover.
A
To Next Page
