Dell 3115CN - Removal Flows; Chapter 3 Removal and Replacement Procedures (Rrps)

3 - 4
Chapter 3 Removal and Replacement Procedures (RRPs)
Version 1 2006.11.28
Removal Flows
The components not connected with arrows in the flow below can be removed independently.
ADF SCANNER ASSY (Removal72)
ADF ASSY, SCANNER ASSY (Removal73)
TRAY ASSY MAIN (Removal75)
Opening FRONT COVER
FUSER (Removal8)
SPUR ASSEMBLY (Removal9)
TONER CARTRIDGE (K), (C), (M), (Y) (Removal6) DUPLEX GATE (Removal7)TRANSFER BELT (Removal4)
DUPLEX MODULE (Removal5)
CHUTE ASSY EXIT OUT (Removal10)
CHUTE ASSY EXIT OUT (Removal10)
OPERATOR PANEL (Removal56)
FEED DRIVE ASSEMBLY (Removal15)
INTEGRATED FEEDER ASSEMBLY (Removal16) TONER CARTRIDGE SENSOR ASSEMBLY (C), (M), (Y) (Removal21)
MPF FEED SOLENOID (Removal14) SIZE SWITCH ASSEMBLY (Removal19)
REAR COVER (Removal49)
COVER BOTTOM (Removal50)
COVER POLE IN L (Removal57)
COVER POLE L (Removal58)
COVER POLE IN L (Removal57)
COVER POLE L (Removal58)
LEFT COVER (Removal59)
COVER POLE IN R (Removal51)
COVER POLE R (Removal52)
RIGHT COVER (Removal54)
FRONT COVER (Removal55)
TONER DISPENSER MOTOR (Removal26)LED ASSEMBLY (Removal25)
LEFT COVER (Removal59)
BOX ASSY PRT AIO (Removal60)
BOX ASSY FAX AIO (Removal62)
HUMIDITY SENSOR (Removal66)
MACHINE CONTROL UNIT (Removal67)
TOP COVER (Removal68)
BOX ASSY PRT AIO (Removal60)
BOX ASSY FAX AIO (Removal62) SPEAKER ASSY (Removal69)
PRINT HEAD (Removal34)
INTERLOCK SWITCH (Removal70)
FAN (Removal71)HIGH VOLTAGE POWER SUPPLY (Removal32)
RIGHT ARM ASSEMBLY (Removal18)
LEFT ARM ASSEMBLY (Removal24)
COVER EXTENDER(Removal48) TRAY REAR COVER (Removal3)MPF COVER (Removal2)
PRINTER Removal FLOW
PHOTOCONDUCTOR (PC) / DEVELOPER (DEV) DRIVE (Removal36)
TONER CARTRIDGE SENSOR ASSEMBLY (K) (Removal37)
ADF FEED ROLLER, ADF SEPARATOR PAD, ADF SEPARATOR SPRING (Removal74)
