Chapter 1 Troubleshooting
Version 1 2006.11.21
FIP-1. 45 CRUM ID 009-367/009-368/009-369/009-370
Are the Toner
Cartridges installed to
the printer the DELL
Toner?
NoYes
Possible causative parts:CARTRIDGE ASSY K (PL5.1.18)
CARTRIDGE ASSY C (PL5.1.19)
CARTRIDGE ASSY M (PL5.1.20)
CARTRIDGE ASSY Y (PL5.1.21)
PWBA MCU (PL9.1.20)
Checking the Toner Cartridge
Checking the Toner
Cartridge installation
Reseat the Toner
Cartridge.
Does the error still
occur when turning
on the power?
NoYes
Checking after replacing
the Toner Cartridge
Replace the Toner
Cartridge.
END
Set the non-DELL
toner mode through
the control panel.
Does the error still
occur when turning
on the power?
NoYes
END
Is the toner cartridge
installed the 3115 cn?
NoYes
Checking the DELL toner type
Replace the toner
cartridge.
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
