Dell 3115CN - Fip-1; No Answer

1‑174
Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 69 Communication 033-500/033-511/033-782/033-799/034-730/035-702/035-704/
035-705/035-708/035-709/035-710/035-716/035-717/035-728/035-729/035-737/
035-797/035-739/035-740/035-741/035-742/035-772/035-780/
Codec Error 033-514/033-515/033-516/Buffer 033-775/033-777/033-784/
No Answer 035-718
Regarding a fax error, a communication test is available between the customer and
Dell, thereby allowing you to analyze the trouble.
The communication test can be performed from the customer to the Dell site for
transmission errors, and from the Dell site to the customer for reception errors.
Possible causative parts: PWBA HYUI (PL13.4.1)
Checking the sending fax
side protocol
Check the [protocol
monitor] in [Report].
Does the sending fax
protocol meet the
spec.?
NoYes
Change the sending fax
side setting.
Checking the PWBA HYUI
installation
Reseat the PWBA HYUI.
(Removal64/Replacement
58)
Does the error still
occur when faxing?
NoYes
END
Replace the PWBA HYUI.
(Removal64/Replacement
58)
Checking the printer setting.
No
Set the [Country] correctly.
Yes
Checking the telephone
line connection
Reseat the telephone line
connector on the PWBA
HYUI.
Does the error still
occur when faxing?
NoYes
END
Is the [Country] of
[Fax setting] on the
[Admin Menu]
correct?
