Dell 3115CN - Fip-1; Fip-1. 62 Restart Printer

1‑164
Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 62 Restart Printer 010-359
Does the error still
occur when turning
on the power?
NoYes
Possible causative parts:FUSER ASSY (PL6.1.10)
PWBA MCU (PL9.1.20)
Checking the FUSER
ASSY type
Checking the FUSER
ASSY installation
Reseat the FUSER ASSY.
Is the FUSER ASSY
installed the 3115CN
FUSER?
NoYes
END
END
Checking after replacing the
FUSER ASSY
Replace the FUSER ASSY.
Does the error still
occur when turning
on the power?
NoYes
END
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
