Dell 3115CN - Error Code Fip

1‑83
Chapter 1 Troubleshooting
Version 2 2007.05.22
6. Error Code FIP
FIP-1. 1 Restart Printer 001-360/001-363
NoYes
Possible causative parts:FAN MAIN (PL13.5.10)
LVPS (PL13.5.14)
PWBA MCU (PL9.1.20)
Checking the FAN MAIN
Does the FAN MAIN function
normally?
Checked by [Digital Output] - [DO-1e]
in [IOT Diagnosis].
In the test, close the INTERLOCK
SWITCH.
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
Checking after replacing
the FAN MAIN
Replace the FAN MAIN.
(Removal 71/Replacement
51)
Does the error still
occur when turning
on the power?
NoYes
END
Checking after replacing
the PWBA MCU
Replace the PWBA MCU.
(Removal 67/Replacement
55)
Does the error still
occur when turning
on the power?
NoYes
END
Replace the LVPS.
(Removal 65/
Replacement 57)
