Chapter 8 Printer Specifications
Version 2 2007.03.20
12.1.6 Transmission Time
The time (T
P
) to transmit image data in G3 communication is defined in the table below. Resolution is
not converted during transmission and density is normal.
*1: Reference
12.1.7 Protocol Control Time
When data error is not identified, protocol control time (Tm, Tn, Tu) is as follows:
- V.17, V.29, V.27ter
-V.34
12.1.8 Throughput
Sending time is calculated in the following formula:
Sending time = Setup time + Tm + (N X Tp) + {(N-1) X Tn} + Tu (sec.)
(N: Send quantity, TP: Image transmission time)
Chart / Mode
14.4Kbps
(MMR)
28.8Kbps
(MMR)
33.6Kbps
(JBIG)*1
The Institute of Image Electronics Engineer of
Japan No.4 / Super Fine (400dpi)
43 sec. or less 22 sec. or less 17 sec. or less
Fine 22 sec. or less 11 sec. or less 9 sec. or less
Standard 16 sec. or less 8 sec. or less 6 sec.or less
ITU-T No.1 / Super Fine 30 sec. or less 13 sec.or less 10 sec. or less
Fine 13 sec. or less 6 sec. or less 5 sec. or less
Standard 9 sec. or less 5 sec. or less 4 sec. or less
FX English Sales Chart / Standard 6 sec. or less 3 sec. or less 2 sec. or less
FX Japanese Sales Chart / Standard 8 sec. or less 4 sec. or less 3 sec. or less
The Institute of Image Electronics Engineer of
Japan No.1 / Standard (Text/Photo)
73 sec. or less 37 sec. or less 20 sec. or less
The Institute of Image Electronics Engineer of
Japan No.1 / Standard (Photo)
120 sec. or less 60 sec. or less 20 sec. or less
Mode
Before
messages: Tm
Between
messages: Tn
After
messages: Tu
Total
Standard protocol 16.4 sec. or less 3.2 sec. or less 4.4 sec. or less 24.0 sec. or less
Mode
Before
messages: Tm
Between
messages: Tn
After
messages: Tu
Total
Standard protocol 9.9 sec. or less 1.0 sec. or less 0.9 sec. or less 11.8 sec. or less
