Dell 3115CN - Fip-1. 71 Codec Error

1‑176
Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 71 Codec Error 033-510
Regarding a fax error, a communication test is available between the customer and
Dell, thereby allowing you to analyze the trouble.
Possible causative parts: PWBA HYUI (PL13.4.1)
Checking the firmware
version
Is the firmware
current version?
PWBA HYUI/PWBA ESS:
200612191047 or later
Checked by the [System
Settings] of the [Reports]
on the [Setup].
No
Yes
Checking the printer
setting
Enter the [Fax/Scanner
Diag] of the Diagnosis.
Is the [G3M RX
Coding] value in the
[Fax Parameter] of the
[Parameter] the
[MMR]?
NoYes
Checking the PWBA HYUI
installation
Reseat the PWBA HYUI.
Checking the error
Does the error
still occur when
faxing after turning off
and on the
power?
NoYes
Does the error still
occur when faxing?
NoYes
END
Replace the PWBA HYUI.
(Removal 64/Replacement
58)
END
Upgread the firmware.
Set the [G3M RX Coding]
value to the [MMR].
