Dell 3115CN User Manual

2 - 9
Chapter 2 Operation of Diag.
Version 1 2006.11.21
4. The Kind of Diag. and Contents of a Test
4.1 FAX Scanner Diag.
4.1.1 Executing FAX Scanner Diag
1) Turn off the power.
2) Turn on the power while holding down “  ” and “  ” keys.
3) Release the fingers from the keys when “ Please wait...” is displayed.
4) The “FAX /Scanner Diag” and “ Printer Diag ” are displayed. (Entered the Customer Diag.
mode.)
5) Press “ 3 ” key. (Entered the FAX /Scanner Diag. mode.)
6) Press “  ” or “  ” key to select the test item.
7) Press “ 3 ” key twice to execute the test.
To exit the test or to return to one step higher menu, press "CANCEL" key.
4.1.2 Information
- Scan Counter
The value of scan count is displayed. FB: Scanning of platen mode/ADF: Scanning of ADF mode.
- Version
The software versions are displayed.
4.1.3 Scanner Maintenance
- White Balance
Enables automatic calibration of the correction value for platen scanning (FB) and ADF scanning
(ADF).
- Parameter
Enables manual calibration of the registration adjustment value or correction value. Use this
menu to enter the correction value when replacing the scanner.
- Counter Clear
Initializes the counter value of platen scanning (FB) and ADF scanning (ADF). Use this menu to
enter the correction value when replacing the scanner.
Main Main program version
Param Parameter version
Boot Boot program version
Dload Down load program version
IIT Scanner and ADF control program version
Panel Control panel program version

Dell 3115CN Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Print speed (color, normal quality, A4/US Letter)	17 ppm
Digital sender	No
Maximum duty cycle	60000 pages per month
Number of print cartridges	4
Scanner type	Flatbed scanner
PC free copying	Yes
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	200
Multi-Purpose tray input capacity	150 sheets
Sound power level (standby)	40 dB
Sound pressure level (printing)	52 dB
Display	LCD
Market positioning	Business
Safety	IEC/EN60950-1:2001; IEC60825-1; CE Mark (EU); NEMKO; GS Mark; GOST & Hygienic; SASO; SABS; UL/cUL Listed; FDA/DHHS
Dimensions (WxDxH)	460 x 570 x 730 mm
Power requirements	220-240V, 47 - 63 Hz
Networking features	Ethernet 10/100 BaseT
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	1152 GB
Color all-in-one functions	print, scan
Compatible operating systems	Windows Vista/Vista x64, Microsoft Windows XP SP1-2, XP 64 bit, NT 4.0 SP6a, 2000 SP2-4, Server 2003 SP1, Server 2003 x64, Mac OS X, UNIX (SolarisTM 10, HP-UX11i), Linux (Red Hat 8/9, SuSE 9, TurboLinux 10)
Paper tray media types	Card stock, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	DellTCP/IP & UDP/IP (LPD, Port9100, IPP6, SMB6, Netware v 5, FTP, HTTP, HTTPS6, RARP, AutoIP, WINS6, SMTP, FTP, DDNS6, SNMP, DHCP, BOOTP, mDNS6); NetBEUI (SMB6); Netware P-server6; Ethertalk6; AppleTalk
Standard interfaces	USB 2.0
Bundled software	ScanSoft PaperPort v10, Dell Printer Configuration Web Tool, Dell Colour Track 2, Dell Toner Management System
Sustainability certificates	ENERGY STAR
Power consumption (off)	0 W
Power consumption (standby)	108 W
Power consumption (PowerSave)	18 W
Power consumption (average operating)	465 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	5 - 32 °C
Storage relative humidity (H-H)	15 - 80 %
Operating relative humidity (H-H)	15 - 85 %
Certification	CE; EN55022:1994 Class B+A1:1995+A2:1997; EN61000-3-2:2000+A2:2005; EN 61000-3-3:1995+A1:2001; EN55024:1998+A1:2001+A2:2003; FCC CFR; ICES-003; GOST; SABS
