Dell 3115CN - Removal 32 HIGH VOLTAGE POWER SUPPLY (PL5.1.17)

3 - 49
Chapter 3 Removal and Replacement Procedures (RRPs)
Version 2 2007.03.20
Removal 32 HIGH VOLTAGE POWER SUPPLY (PL5.1.17)
Steps 1 through 14 are for reference. Before removing this component, check that Steps 1 through 14
have been performed.
1) Open FRONT COVER (PL13.2.1).
2) Remove the FUSER.(Removal 8)
3) Remove the REAR COVER. (Removal 49)
4) Remove the COVER BOTTOM. (Removal 50)
5) Remove the COVER POLE IN R.(Removal 51)
6) Remove the COVER POLE R.(Removal 52)
7) Remove the RIGHT COVER. (Removal 54)
8) Remove the COVER POLE IN L. (Removal 57)
9) Remove the COVER POLE L. (Removal 58)
10) Remove the LEFT COVER. (Removal 59)
11) Remove the TOP COVER. (Removal 68)
12) Remove the BOX ASSY PRT AIO. (Removal 60)
13) Remove the BOX ASSY FAX AIO. (Removal 62)
When performing the step described below, it is not necessary to remove the connector
and harness of the FAN
14) Remove the FAN.(Removal 71)
Continues to the next page.
