Dell 3115CN - Fip-1; Fip-1. 47 Replace Cart

1‑149
Chapter 1 Troubleshooting
Version 1 2006.11.21
FIP-1. 47 Replace Cart. 093-930
Possible causative parts:CARTRIDGE ASSY Y (PL5.1.21)
PWBA MCU (PL9.1.20)
END
Yes
No
Is the life counter
going to reach the
replacement time?
Confirming the toner
life counter.
Replace the Toner
Cartridge.
Yes
No
Is the toner cartridge
installed correctly?
Checking the toner
cartridge installation.
Does the error still
occur when the
power is turned ON?
No
Checking after replacing
the toner cartridge.
Replace the toner
cartridge.
Does the error still
occur when the
power is turned ON?
Yes
No
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
END
Reseat the toner
cartridge.
Yes
