Dell 3115CN - Mechanical Properties; Dimensions;Mass of Printer; Dimensions;Mass of Paper Tray

8 – 3
Chapter 8 Printer Specifications
Version 2 2007.03.20
3. Mechanical Properties
3.1 Dimensions/Mass of Printer
* Including MSI with its cover being closed. And the
ejection stacker is also being contained in the main
unit.
As regards Depth, 570mm at Legal 14.
3.2 Dimensions/Mass of Paper Tray
(Except COVER OPT FDE L and COVER OPT FDR R)
Width(mm) Depth(mm) Height(mm) Mass(kg)
460 520 730
36 kg (without CRU)
40 kg (with CRU)
Tray Width(mm) Depth(mm) Height(mm) Mass(kg)
For 550 sheet 386 506.7 134.4 7.9 or less
Gnb08005KA
Gnb08006KA
