§ 11 550 FEEDER
PWBA MCU
PL9.1.20
P/J27
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
P/J273
HARNESS ASSY FDR UNIT
PL12.2.3
HARN ASSY R SIDE AIO
PL13.6.12
P/J419
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
9
10
3
4
5
P/J421
6
7
8
9
SG
SG
SG
I/L +24VDC
I/L +24VDC
+3.3VDC
TRAY SEN
Rxd
Txd
SG
PWBA OPT FDR
HARNESS ASSY C2 TURN
PL12.2.8
HARNESS ASSY C2 MOT
PL12.2.9
HARNESS ASSY C2 CHUTE
PL12.2.7
HARNESS ASSY C2 NO PAPER
PL12.3.30
PL12.2.6
P/J422 P/J4222
P/J4221
1
2
3
4
4
3
2
1
5
6
2
1
DRIVE ASSY
OPT FEED
PL12.2.10
M
P/J42121
3
2
1
PULL UP +3.3VDC
SG
PAPER EMPTY SENSED (L) +3.3VDC
CST NO PAPER
SENSOR
PL12.3.14
P/J4211
4
3
2
C2 PAPER SIZE SW 3 ON (L) +3.3VDC
C2 PAPER SIZE SW 2 ON (L) +3.3VDC
C2 PAPER SIZE SW 1 ON (L) +3.3VDC
SG
FEED MOT ON
FEED MOT ALARM
FEED MOT CLK
FEED MOT LOW
SG
I/L +24VDC
1
SWITCH ASSY
SIZE OPT
PL12.2.5
P/J4212
3
2
1
1
2
3
I/L +24VDC
TURN CL ON (L) +24VDC
P/J4201P/J420
3
1
1
3
1
3
CLUTCH ASSY
PH TURN
PL12.1.5
I/L +24VDC
FEED CL ON (L) +24VDC
P/J4213
2
1
1
2
1
2
CLUTCH ASSY
PH FEED
PL12.1.6
GNB07012KA
INTERLOCK
+24VDC
INTERLOCK
+24VDC
INTERLOCK
+24VDC
INTERLOCK
+24VDC
+3.3VDC
INTERLOCK
+24VDC
+3.3VDC
+3.3VDC
*CN2
*CN1
* The CN1 and CN2 are
printed on the board.
