1‑66
Chapter 1 Troubleshooting
Version 1 2006.11.21
5.4 LCD Display
Problem Error Message Error Contents
Relevant
FIP
Paper Jam
Paper Jam
071-100 Printer
Open Tray1
Remove Paper
Open & close
Front Cover
<IOT 250 Feeder Misfeed JAM>
The Regi sensor is not turned on within the specified
time.
FIP-1. 37
Paper Jam
072-100 Printer
Open Tray2
Remove Paper
Open & close
Front Cover
<IOT Option Feeder Misfeed JAM>
The Regi sensor is not turned on within the specified
time.
FIP-1. 38
Paper Jam
075-100 Printer
Check MPF
Remove Paper
Open & close
Front Cover
<IOT MPF Misfeed JAM>
The Regi sensor is not turned on within the specified
time.
FIP-1. 39
Paper Jam
077-900 Printer
Open Front Cover
Remove Paper
<IOT Remaining Paper JAM>
-The paper remains at the Exit Sensor.
-The paper does not reach the Exit Sensor within the
specified time.
-The paper passed Exit Sensor earlier than the
specified times.
FIP-1. 40
Paper Jam
077-901 Printer
Open Front Cover
Remove Paper
<IOT Remaining Paper JAM>
-The paper remains at the Regi Sensor.
-The paper does not reach the Exit Sensor within the
specified time after the Regi Sensor is ON.
-The paper does not pass through the Regi Sensor
within the specified time.
FIP-1. 40
Paper Jam
077-903 Printer
Open Tray1
Remove Paper
Open & close
Front Cover
<IOT Feed JAM>
The arrival time of the regi sensor is early than the
specified time.
FIP-1. 41
Paper Jam
077-907 Printer
Open Front Cover
& Belt Unit
Remove Paper
<IOT Remaining Paper JAM>
-The paper remains at the Dup Jam Sensor.
-The paper reached Dup Jam Sensor earlier than
the specified time.
-The paper passed Dup Jam Sensor earlier than the
specified time.
-The paper does not pass through the Dup Jam
Sensor within the specified time.
-The paper does not reach the Regi Sensor within
the specified time, after the Dup Jam Sensor is ON.
FIP-1. 42
