FIP-1. 91 Over Heat 042-700/Copy Scan Fax 142-700
Possible causative parts:KIT FEEDER (PL3.2.99)
PWBA MCU (PL9.1.20)
No
Yes
Checking the
printing
Checking the printing after
cool down of five minutes.
Did the
client print the large
volume of
printing?
Checking the PWBA MCU
Reseat the PWBA MCU.
(Removal 67/Replacement
55)
Does the error
still occur when
printing?
NoYes
END
Does the error
still occur when
printing?
NoYes
END
Checking after replacing
the PWBA MCU
Replace the PWBA
MUC.(Removal 67/
Replacement 55)
Does the error
still occur when
printing?
No
Yes
END
Replace the KIT FEEDER.
(Removal 16/Replacement
30)
Checking the room temperature
Is the room
temp. over 32
degrees C ?.
No
Yes
Change the room or
cool down the room
