Dell 3115CN - Cyan Toner Cartridge; Installation Space (Min. Installation Space)

8 – 6
Chapter 8 Printer Specifications
Version 2 2007.03.20
3.4.6 Cyan toner cartridge
Width: 303.8mm
Depth: 150mm
Height: 53.8mm
Mass: 1.05 (4K)/1.05 (8K) kg
Reference:The Cyan toner cartridge has
CRUM (CRU memory) to record
information.
3.5 Installation Space (min. installation space)
Minimum space as shown below is required to install the printer when it is used for normal objects.
(Space occupied by the operator is not included.)
Top view
Kmy08010KA
100mm
Gnb08011KA
600mm
100mm
100mm
