Dell 3115CN - Connector [P (Plug); J (Jack)]; List of P;J

4 – 1
Chapter 4 Plug/Jack(P/J) Connector Locations
Version 2 2007.03.20
1. Connector [P (plug) / J (jack)]
1.1 List of P/J
IOT
P/J Coordiates Remarks
3E-138
Connects ELECTRONIC SUB-SYSTEM CONTROL BOARD and MULTI
PROTOCOL CARD
10 I-157 Connects MACHINE CONTROL UNIT and IF AIO Harness Assembly
11 I-157
Connects MACHINE CONTROL UNIT and VIDEO AIO Harness
Assembly
12 I-156 Connects MACHINE CONTROL UNIT and ROS AIO Harness Assembly
14 I-156 Connects MACHINE CONTROL UNIT and LVPS AIO Harness Assembly
15 H-157 Connects MACHINE CONTROL UNIT and 24V AIO Harness Assembly
16 I-156
Connects MACHINE CONTROL UNIT and HIGH VOLTAGE POWER
SUPPLY
17 I-156
Connects MACHINE CONTROL UNIT and FUSER AIO Harness
Assembly
18 H-157
Connects MACHINE CONTROL UNIT and TNR MOT AIO Harness
Assembly
19 I-157
Connects MACHINE CONTROL UNIT and TNR SNR AIO Harness
Assembly
21 H-158
Connects MACHINE CONTROL UNIT and R SIDE AIO Harness
Assembly
22 H-158
Connects MACHINE CONTROL UNIT and R SIDE AIO Harness
Assembly
23 H-159
Connects MACHINE CONTROL UNIT and R SIDE AIO Harness
Assembly
24 I-159 Connects MACHINE CONTROL UNIT and OHP AIO Harness Assembly
25 H-158
Connects MACHINE CONTROL UNIT and R SIDE AIO Harness
Assembly
26 I-159 Connects MACHINE CONTROL UNIT and HUM Harness Assembly
27 I-159
Connects MACHINE CONTROL UNIT and R SIDE AIO Harness
Assembly
31 I-159 Connects MACHINE CONTROL UNIT and CRUM AIO Harness Assembly
40a F-153
Connects LOW VOLTAGE POWER SUPPLY and IF AIO Harness
Assembly
40b F-153
Connects LOW VOLTAGE POWER SUPPLY and ESS POWER AIO
Harness Assembly
44 F-152 Connects LOW VOLTAGE POWER SUPPLY and INTERLOCK SWITCH
47 F-152
Connects LOW VOLTAGE POWER SUPPLY and FUSER AIO Harness
Assembly
48 E-152
Connects LOW VOLTAGE POWER SUPPLY and INLET AIO Harness
Assembly
48 H-144 Connects PWBA HYUI and AIO-ESS Harness Assembly
50 J-142 Connects PWBA HYUI and ESS POWER AIO Harness Assembly
52 H-141 Connects PWBA HYUI and SPEAKER ASSY
53 I-144 Connects PWBA HYUI and A-OP-ESS Harness Assembly
56 I-143 Connects PWBA HYUI and PWBA FAX
60 J-143
"Connects PWBA HYUI and ADF SCANNER ASSY (Empty Sensor, PCB
Sensor)"
61 J-143 Connects PWBA HYUI and ADF SCANNER ASSY (ADF Open Sensor)
62 J-143 Connects PWBA HYUI and ADF SCANNER ASSY (ADF Motor)
63 J-143 Connects PWBA HYUI and ADF SCANNER ASSY (Scanner Motor)
