4 – 2
Chapter 4 Plug/Jack(P/J) Connector Locations
Version 2 2007.03.20
64 I-142 Connects PWBA HYUI and ADF SCANNER ASSY (PCB CCD)
65 J-142 Connects PWBA HYUI and ADF SCANNER ASSY (PCB CCD)
101 F-138
Connects ELECTRONIC SUB-SYSTEM CONTROL BOARD and IF AIO
Harness Assembly
101 I-158 Not Connects (Debug only)
111 F-138
Connects ELECTRONIC SUB-SYSTEM CONTROL BOARD and VIDEO
AIO Harness Assembly
121 G-123 Connects PRINT HEAD and ROS AIO Harness Assembly
141 I-136 Connects LED ASSEMBLY and LVPS AIO Harness Assembly
144 C-110
Connects PWBA EEPROM (BELT) and BELT Harness Assembly
(TRANSFER BELT)
144 D-153 Connects PWBA EEPROM (XPRO) and R SIDE AIO Harness Assembly
161 G-136
Connects HIGH VOLTAGE POWER SUPPLY and MACHINE CONTROL
UNIT
171 G-108 Connects FUSER and FUSER AIO Harness Assembly
181 I-138
Connects TONER DISPENSER (Y) and TNR MOT AIO Harness
Assembly
182 I-137
Connects TONER DISPENSER (M) and TNR MOT AIO Harness
Assembly
183 H-136
Connects TONER DISPENSER (K) and TNR MOT AIO Harness
Assembly
184 H-137
Connects TONER DISPENSER (C) and TNR MOT AIO Harness
Assembly
191 G-126
Connects TONER CARTRIDGE SENSOR ASSEMBLY (Y) and TNR SNR
AIO Harness Assembly
192 G-125
Connects TONER CARTRIDGE SENSOR ASSEMBLY (M) and TNR SNR
AIO Harness Assembly
193 G-124
Connects TONER CARTRIDGE SENSOR ASSEMBLY (K) and TNR SNR
AIO Harness Assembly
194 G-124
Connects TONER CARTRIDGE SENSOR ASSEMBLY (C) and TNR SNR
AIO Harness Assembly
202 F-108 Connects OPERATOR PANEL and A-OP-OPP Harness Assembly
211 G-109
Connects PHOTOCONDUCTOR(PC) / DEVELOPER(DEV) DRIVE (Main
Motor) and R SIDE AIO Harness Assembly
221 G-110
Connects PHOTOCONDUCTOR(PC) / DEVELOPER(DEV) DRIVE (Sub
Motor) and R SIDE AIO Harness Assembly
222 G-111
Connects PHOTOCONDUCTOR(PC) / DEVELOPER(DEV) DRIVE (Deve
Motor) and R SIDE AIO Harness Assembly
231 H-127 Connects SIZE SWITCH ASSEMBLY and R SIDE AIO Harness Assembly
232 H-126
Connects INTEGRATED FEEDER ASSEMBLY (REGI SNR Harness
Assembly) and R SIDE AIO Harness Assembly
233 H-125
Connects INTEGRATED FEEDER ASSEMBLY (REGI Clutch) and R
SIDE AIO Harness Assembly
234 H-125
Connects INTEGRATED FEEDER ASSEMBLY (Turn Clutch) and R SIDE
AIO Harness Assembly
235 H-124
Connects INTEGRATED FEEDER ASSEMBLY (CST Feed Clutch) and R
SIDE AIO Harness Assembly
236 G-112 Connects MPF FEED SOLENOID and R SIDE AIO Harness Assembly
241 H-126 Connects OHP SNR Harness Assembly and OHP AIO Harness Assembly
251 G-111
Connects FEED DRIVE ASSEMBLY (PH Motor) and R SIDE AIO Harness
Assembly
261 I-153 Connects HUMIDITY SENSOR and HUM Harness Assembly
P/J Coordiates Remarks
