Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 40 Paper Jam 077-900/077-901
If the paper actually loaded in the tray or cassette does not match the [Paper Tray]
setting under [Tray Setting], continuing printing in that status may cause a jam
eventually.
No
Yes
Possible causative parts:KIT FEEDER (PL3.2.99)
FUSER ASSY (PL6.1.10)
DRIVE ASSY MAIN (PL8.1.2)
DRIVE ASSY PH (PL8.1.7)
PWBA MCU (PL9.1.20)
Checking the paper
condition
A
Replace the paper or the
transparency with a new
and dry one.
Is the paper or the
transparency in the
Tray wrinkled or
damaged?
Checking the Front Cover
latching
Open and close the Front
Cover, check the latching.
No
Yes
Does the error still
occur when printing?
END
No
Yes
Checking the paper type
Check the paper type below.
- Paper in the cassette or the tray.
- Paper type setting by the control
panel.
Are these paper type
same?
NoYes
Does the error still
occur when printing?
END
Change the paper type
Replace the FUSER ASSY.
