1‑133
Chapter 1 Troubleshooting
Version 1 2006.11.21
B
Checking the Feed Roll and
turn roll for shape and
operation
Remove the paper cassette.
Yes
Checking the after
replacing the 250 PAPER
CASSETTE.
Replace the 250 PAPER
CASSETTE..
No
END
Does the error still
occur when printing?
Yes
Are rollers installed correctly?
Also are they not conterminated
or damaged, and rotate smoothly?
Check these items by turning
them with your fingers.
No
Replace the KIT ROLLER.
If error occurred, replace the
KIT FEEDER. (Removal 16/
Replacement 30)
No
END
Does the error still
occur when printing?
Yes
Replace the PWBA
MCU. (Removal 67/
Replacement 55)
Checking the after
replacing the KIT FEEDER
Replace the KIT FEEDER.
(Removal 16/Replacement
30)
