Chapter 1 Troubleshooting
Version 1 2006.11.21
7.4 Image Quality FIP
FIP-1.P1 Faint print (Low contrast)
Trouble substance
The density of the image is entirely too faint.
ESS and possible causative parts
- TRANSFER ASSY (PL4.1.1)
- DISPENSOR ASSY (PL5.1.12)
- HVPS (PL5.1.17)
- CARTRIDGE ASSY (PL5.1.18(K)/PL5.1.19 (C)/PL5.1.20 (M)/PL5.1.21 (Y))
- KIT ROS ASSY (PL13.3.99)
- PWBA MCU (PL9.1.20)
- PWBA ESS (PL13.4.20)
Before starting troubleshooting, check the paper transfer path. Make sure that there is no foreign
materials on the transfer path, such as staples, paper clips, scraps of paper and so on.
ABCDEabcde12345
