Dell 3115CN - Fip-1. 78 no Answer

1‑184
Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 78 No Answer 035-701
Regarding a fax error, a communication test is available between the customer
and Dell, thereby allowing you to analyze the trouble.
Possible causative parts: PWBA HYUI (PL13.4.1)
Is the [Country]
of the [Fax setting] on
the [Admin Menu]
correct?
NoYes
Checking the PWBA FAX
installation
Reseat the PWBA FAX on
the PWBA HYUI.
Checking the fax number
Is the fax number
correct?
NoYes
Retry the fax.
A
Set the [Country] corrctly.
Checking the telephone
line connection
Reseat the telephone line
connector on the PWBA
HYUI.
Does the error still
occur when faxing?
NoYes
END
Checking the printer
setting
