1‑132
Chapter 1 Troubleshooting
Version 1 2006.11.21
A
Checking the Regi Sensor
for operation
No
Yes
Does the number
on the screen increase by one,
every time the actuator of the regi
sensor is operated?
Checked by [Digital Input]-[DI-3]
in [IOT Diagnosis].
Checking the Feed
Solenoid MSI for operation
No
Yes
Replace the KIT FEEDER.
(Removal 16/Replacement
30)
Replace the KIT SOLENOID
FEED MSI. (Removal 14/
Replacement 32)
Does the feed solenoid operate
properly?
Checked by [Digital Output]-[DO-
2d] in [IOT Diagnosis].
B
Checking the Turn Clutch
for operation
No
Yes
Does the turn clutch
operate properly?
Checked by [Digital
Output]-[DO-2b] in [IOT
Diagnosis].
Replace the KIT FEEDER.
(Removal 16/Replacement
30)
