Chapter 1 Troubleshooting
Version 2 2007.05.22
A
B
Checking the Regi Sensor
for operation
No
Yes
Does the number
on the screen increase by one,
every time the actuator of the exit
sensor is operated?
Checked by [Digital Input]-[DI-3]
in [IOT Diagnosis].
Replace the KIT FEEDER.
(Removal 16/Replacement
30)
Checking the Exit Sensor
for operation
NoYes
Checking the FUSER
ASSY installation
Reseat the FUSER ASSY.
No
Yes
Does the error still
occur when printing?
END
Replace the FUSER
ASSY.
Does the number
on the screen increase by one,
every time the actuator of the exit
sensor is operated?
Checked by [Digital Input]-[DI-2]
in [IOT Diagnosis].
