Chapter 1 Troubleshooting
Version 2 2007.05.22
C
No
Yes
Checking the regi clutch for
operation
Does the feed motor
operate properly?
Checked by [Digital
Output]-[DO-a] in [IOT
Diagnosis].
Replace the DRIVE ASSY
PH. (Removal 15/
Replacement 31)
Checking the Main Motor
for operation
No
Yes
Checking the sub motor for
operation
NoYes
Replace the MAIN DRIVE
ASSY. (Romoval 36/
Replacement 10)
Replace the MAIN DRIVE
ASSY. (Romoval 36/
Replacement 10)
Does the main motor operate
properly?
Checked by [Digital Output]-[DO-
0] in [IOT Diagnosis].
Does the feed motor operate
properly?
Checked by [Digital Output]-[DO-
5] in [IOT Diagnosis].
Checking the PH motor for
operation
B
