Dell 3115CN - Page 143

1‑117
Chapter 1 Troubleshooting
Version 2 2007.05.22
FIP-1. 32 Restart Printer 062-323/123-314
Possible causative parts: CONSOLE PANEL (PL13.2.2)
PWBA HYUI (PL13.4.1)
Checking the PWBA HYUI
installation
Reseat the PWBA HYUI.
(Removal64/Replacement
58)
Does the error still
occur when turning
on the power?
NoYes
END
Checking the CONSOLE
PANEL installation
Reseat the CONSOLE
PANEL. (Removal 56/
Replacement 66)
Does the error still
occur when turning
on the power?
NoYes
END
Checking the PWBA HYUI
installation
Reseat the PWBA HYUI.
(Removal64/Replacement
58)
A
Checking the error
Wait for five seconds and
turn ON the power after the
power is turned OFF.
Does the error still
occur when
copying?
NoYes
END
