Chapter 1 Troubleshooting
Version 1 2006.11.21
A
B
Checking the document
path
Is there the foreign
substance on the
document path?
NoYes
Remove the foreign
substance.
Checking after replacing
the ADF SCANNER ASSY
Replace the ADF
SCANNER ASSY.
(Removal 72/Replacement
50)
Does the error still
occur when copying?
NoYes
Replace the PWBA HYUI.
(Removal64/Replacement
58
END
NoYes
Is the roller
installed correctly?
Also are they not
contaminated or damaged,
and rotate smoothly?
Replace the ADF
SCANNER ASSY.
(Removal 72/
Replacement 50)
Replace the ADF FEED
ROLLER. (Removal 74/
Replacement 48)
Checking the ADF Feed
Roller installation
