1‑223
Chapter 1 Troubleshooting
Version 1 2006.11.21
B
Is the installed toner
cartridge the DELL
toner?
NoYes
Checking the toner
cartridge.
Replace to
DELL toner.
Is the installed paper
with a new and dry
one?
NoYes
Checking the paper
Replace the paper with
a new and dry.
NoYes
Checking the printer
Is the image
printed correctly?
Checked by [Test Print]-
[Cyan 20%, Magenta 20%,
Yellow 20% and Black
20%] in
diagnosis.
NoYes
Is the image printed
correctly?
END
Checking the TRANSFER
ASSY installation
Reseat the TRANSFER
ASSY.
Check the
printing data.
Does the error occur
when printing or
faxing?
NoYes
Checking the error
mode
A
