7 - 11
Chapter 7 Wiring Diagrams and Signal Information
Version 1 2006.11.21
Signal line name Description
PAPER EMPTY SENSED
(L) +3.3VDC
Paper detect signal of the MSI by the Sensor Photo
(MSI NO PAPER SENSOR)
REGI SENSED (L)
+3.3VDC
Paper detect signal of the Regi part by the Sensor Photo (REGI SENSOR)
REGI CL ON (L) +24VDC ON/OFF signal of the REGI CLUTCH
FEED SOL ON (L)
+24VDC
ON/OFF signal of the MSI FEED SOLENOID
OHP LED ON/OFF signal of the OHP LED
OHP SENSED (L)
+3.3VDC
Detect Signal of the transparency sheet by the Sensor Photo
(OHP SENSOR)
TEMP. Data on temperature inside the printer.
PH MOT ON (X) +XXVDC
PH MOT CLK
PH MOT ALARM
Drive control signal of the DRIVE ASSY PH
To Next Page
