7 - 13
Chapter 7 Wiring Diagrams and Signal Information
Version 1 2006.11.21
Signal line name Description
MAIN MOT ON
MAIN MOT ALARM
MAIN MOT CLK
MAIN MOT LO
MAIN MOT CW/CCW
Drive control signal of the MAIN MOTOR
SUB MOT ON
SUB MOT ALARM
SUB MOT CLK
SUB MOT LO
SUB MOT BRAKE
Drive control signal of the SUB MOTOR
DEVE MOT ON
DEVE MOT ALARM
DEVE MOT CLK
DEVE MOT LO
DEVE MOT BRAKE
Drive control signal of the DEVE MOTOR
EXIT CL ON (L) +24VDC ON/OFF signal of the EXIT CLUTCH
