7 - 23
Chapter 7 Wiring Diagrams and Signal Information
Version 1 2006.11.21
Signal line name Description
Y DISPENSE MOT A
Y DISPENSE MOT B
Y DISPENSE MOT XA
Y DISPENSE MOT XB
Drive control signal of the DISPENSE MOTOR (Y)
M DISPENSE MOT A
M DISPENSE MOT B
M DISPENSE MOT XA
M DISPENSE MOT XB
Drive control signal of the DISPENSE MOTOR (M)
K DISPENSE MOT A
K DISPENSE MOT B
K DISPENSE MOT XA
K DISPENSE MOT XB
Drive control signal of the DISPENSE MOTOR (K)
C DISPENSE MOT A
C DISPENSE MOT B
C DISPENSE MOT XA
C DISPENSE MOT XB
Drive control signal of the DISPENSE MOTOR (C)
CARTRIDGE Y SENSED (L)
+3.3VDC
Detection signal of the CRU SENSOR (Y)
CARTRIDGE M SENSED (L)
+3.3VDC
Detection signal of the CRU SENSOR (M)
CARTRIDGE K SENSED (L)
+3.3VDC
Detection signal of the CRU SENSOR (K)
CARTRIDGE C SENSED (L)
+3.3VDC
Detection signal of the CRU SENSOR (C)
DATA Y IN
DATA Y OUT
Control signal of the CRUM SENSOR (Y)
DATA M IN
DATA M OUT
Control signal of the CRUM SENSOR (M)
DATA C IN
DATA C OUT
Control signal of the CRUM SENSOR (C)
DATA K IN
DATA K OUT
Control signal of the CRUM SENSOR (K)
