7 - 31
Chapter 7 Wiring Diagrams and Signal Information
Version 1 2006.11.21
Signal line name Description
Txd
Rxd
Control signal of the PWBA DUP
DUP MOT A
DUP MOT B
DUP MOT XA
DUP MOT XB
Drive control signal of the DUP MOTOR
DUP IN SENSED (L) +3.3VDC
Paper detect signal of the Duplex by the Sensor Photo
(DUP JAM SENSOR)
DUP CL ON (L) +24VDC ON/OFF signal of the DUP CLUTCH
FAN +24VDC
FAN ALARM
Drive control signal of the DUP FAN
To Next Page
