7 - 35
Chapter 7 Wiring Diagrams and Signal Information
Version 1 2006.11.21
Signal line name Description
SCN-/A
SCN-A
SCN-/B
SCN-B
Drive control signal of the SCANNER MOTOR
ADCLK+
ADCLK-
TG
Control signal of the PCB CCD
ID8-
ID8+
ID7-
ID7+
ID6-
ID6+
ID5-
ID5+
ID4-
ID4+
Image date of the document by the CCD
INV Control signal of the LAMP INVERTOR
AFE*RST
AFEDATA
AFECLK
AFE*CS
Control signal of the PCB CCD
HP SENSED (H) +5VDC Home Position signal of the Carriage by the Sensor Photo
