Chapter 7 Wiring Diagrams and Signal Information
Version 1 2006.11.21
Signal line name Description
ADF-/A
ADF-A
ADF-/B
ADF-B
Drive control signal of the ADF MOTOR
REGI SENSED (H) +5VDC Document detect signal of the Regi part by the Sensor Photo
READ SENSED (H) +5VDC Document detect signal of the Read part by the Sensor Photo
COVER OPEN SENSED (H)
+5VDC
Cover open signal of the ADF COVER by the Sensor Photo
EMPTY SENSED (H) +5VDC Document empty signal of the ADF Tray by the Sensor Photo
ADF OPEN SENSED (H) +5VDC ADF open signal by the Sensor Photo
