Chapter 24
| Multicast Filtering Commands
MLD Filtering and Throttling
– 703 –
ipv6 mld filter
(Global Configuration)
This command globally enables MLD filtering and throttling on the switch. Use the
no form to disable the feature.
Syntax
[no] ipv6 mld filter
Default Setting
Disabled
Command Mode
Global Configuration
Command Usage
â—† MLD filtering enables you to assign a profile to a switch port that specifies
multicast groups that are permitted or denied on the port. An MLD filter profile
can contain one or more, or a range of multicast addresses; but only one profile
can be assigned to a port. When enabled, MLD join reports received on the port
are checked against the filter profile. If a requested multicast group is
permitted, the MLD join report is forwarded as normal. If a requested multicast
group is denied, the MLD join report is dropped.
â—† MLD filtering and throttling only applies to dynamically learned multicast
groups, it does not apply to statically configured groups.
â—† The MLD filtering feature operates in the same manner when MVR6 is used to
forward multicast traffic.
range Specifies one or a range of multicast addresses for a profile IPC
ipv6 mld filter Assigns an MLD filter profile to an interface IC
ipv6 mld max-groups Specifies an M:D throttling number for an interface IC
ipv6 mld max-groups
action
Sets the MLD throttling action for an interface IC
ipv6 mld query-drop Drops any received MLD query packets IC
ipv6 multicast-data-drop Enable multicast data guard mode on a port interface IC
show ipv6 mld filter Displays the MLD filtering status PE
show ipv6 mld profile Displays MLD profiles and settings PE
show ipv6 mld query-drop Shows if the interface is configured to drop MLD query
packets
PE
show ipv6 mld throttle
interface
Displays the MLD throttling setting for interfaces PE
Table 132: MLD Filtering and Throttling Commands (Continued)
Command Function Mode
