258
────────────────────────────────────────────────────
10.7 Printing Procedure
────────────────────────────────────────────────────
1
0.7.8 External Printer (Color Print)
Connect the printer card to the unit.
For details on connection, see Section 13.3.2.
Connecting the PRINTER CARD
S
et the output destination by PRINT key and COPY key
to external printer.
Output destination
For details on settings, see Section 9.6.
Output color
Select color or monochrome.
Control code
Set the control code ("ESC/P" or "ESC/P Raster") according
to the printer to be used.
Save "newly measured data" or "data saved to the media" in
t
he internal memory of the unit.
For details on load, see Section 13.4.5.
P
ress the DISP key; the display screen will appear. Usin
g
c
ursors A and B, the print range can be specified.
F
or information on how to use cursors A and B, see Section
11.2.
W
hen the PRINT key is pressed, the waveform data is
printed out.
PRINT key
COPY key
W
hen the COPY key is pressed, the data shown on the
LCD is printed out.
・Turn on the external printer.
・
Load A4-size sheets and prepare the printer for printing.
Setting the external printer
Setting the Interface
Saving the data in the memory
Specifying the printout range
Printing starts
Printing size
Select the printing size (normal or 1.5 times).
NOTE
Using the 9559 PRINTER CARD, waveform data can be output on A4-size
sheets from the external printer in color or monochrome.
PRINT key: Prints out waveform data or numerical data.
COPY key: Prints out the screen hard copy.
With respect to the following items, the external printer differs from the
internal printer:
・The gauge is printed out for every page.
・When the display format is the X-Y screen, waveform data is printed out in
monochrome.
・For details on settings, see Sections 9.6.1 and 9.6.2.
