314
────────────────────────────────────────────────────
14.6 Recorder & Memory Function (Advanced Version)
────────────────────────────────────────────────────
Time axis ・Recorder
500 ms/DIV
1, 2, 5, 10, 30 s/DIV
1, 2, 5, 10, 30 min/DIV
1 h/DIV
・Memory
100, 200, 500 μs/DIV
1, 2, 5, 10, 20, 50, 100, 200, 500 ms/DIV
1, 2, 5, 10, 30 s/DIV
1, 2, 5 min/DIV
Time axis resolution 100 points/DIV
Sampling period 1/100 of the time axis.......memory waveform
Recording length Any recording length
(*1)
or preset setting (see below)
20, 50, 100, 200, 500, 1000 DIV, continuous (recorder)
20, 50, 100, 200, 500, 1000, 2000 DIV (memory)
Screen・print format Single, dual, quad screen display
Display Switchable between recorder and memory waveforms
Printer output During measurement operation, recorder waveform only. After data
capture, printout of recorder waveform as on display or memory
waveform.
Waveform storage (recorder) Last 1000 divisions of data saved in memory
Can be checked by reverse scrolling and reprinted
Additional recording function ON/OFF
(*2)
Trigger source CH1 to CH8, CHA to CHD and external trigger (memory)
Trigger mode Single, repeat, timer (recorder)
Ancillary function Sequential save
Variable function Provided
Vernier function Provided
4.6 Recorder & Memory Function (Advanced Version)
*1: Set from 1 division to the maximum number of divisions at 1-division intervals
*2: Additional recording function (recording data without paper)
At start choose ON or OFF to process recorded data.
OFF: Deletes recorded data and records from the beginning.
ON: Saves recorded data and continues recording.
When total recorded data reaches over 1000 DIV, overwrites previous data
from the beginning.
