Hioki 8835-01 - Memory Recorder Function Details; Chapter 4 Memory Recorder Function

49
────────────────────────────────────────────────────
4.1 Outline
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
4
.1.1 Outline of the Memory Recorder Function
Chapter
4
Memory Recorder Functio
n
4
.1 Outline
The memory recorder function has the following features.
(1) After being stored in the internal memory, input signal data can be displayed and
printed.
(2) All input channel data are recorded on the same time axis.
Since data for all channels can be superimposed, the relative relationship
between input signals can be observed visually.
(3) Time axis setting
100 μs/DIV to 5 min/DIV
(4) Time axis resolution 100 points/DIV
(5) Storage capacity
40,000 DIV
(6) Waveform magnification/compression display and print
・Time axis direction: ×10 to ×1/5000
・Voltage axis direction: ×10 to ×1/2
With the variable function
(7) Display format
・Time axis waveform: single, dual, quad screen display
・X-Y waveform: dot, line
(8) Printing
・Manual print, partial print, screen hard copy.
・Multiple printing possible.
(9) High-quality print
Smooth print function approximates analog waveform.
(10) Logging function
Numeric printout of waveform data
(11) Pre-trigger function
Allows monitoring of signal also before triggering.
